Automatic Shrink Packing Machine (all closed)

                          Performance characteristics:
                          . This machine adopts PLC programmable control, human-machine interface operation.
                           . The entire closed-end packaging.
                           . Automatic feeding, film wrap, bag, seal   cutting, collection of waste, the whole flat, shrink, packaging, finished a   one-time completion.
                           . Closure temperature cutter-style super alloy,   anti-stick, sealing thin line, non-coking, non-smoke, zero emission.
                           . Cut   after cut to the packaging will automatically rebound.
                           . Packaging size can be   adjusted without changing tooling.
                           . All sets of conveyor belt PTFE insulated   pipes, not hot, does not harm the film.
                           . Shrink a dual circulation of hot air   chamber system, temperature regulation can be arbitrary.
                           . The use of   non-polar transport motor variable speed motor, long life, low noise.

                        The scope of application of:
                        Pharmaceutical, food, stationery, cosmetics, electronic products, toys and so on.
                       Main technical parameters:



                            |
                                 DTBMD-450B



                                      Power Supply  |
                                      380V 50Hz  |


                                      Power  |
                                      7KW  |


                                      Maximum transmission speed  |
                                      10m/min  |


                                      Largest package size  |
                                      400x320mm(WxH)  |


                                      Overall dimensions  |
                                      1600x600x1260mm  |


                                      Machine weight  |
                                      200kg  |


                                      Main material  |
                                      Stainless Steel  |




  |






                            |   |


                            DTBS-400LB



                                      Power Supply  |
                                      220V 50Hz  |


                                      Power  |
                                      1.25KW  |


                                      Maximum cut size of letters  |
                                      560x400x125mm  |


                                      Maximum speed packaging  |
                                      35Bags/min  |


                                      Pressure  |
                                      0.5Mpa  |


                                      Overall dimensions  |
                                      1500x770x1450mm  |


                                      Machine weight  |
                                      350kg  |


                                      Main material  |
                                      Stainless Steel  |


                                  |






  |
